PDC Cutter for Rock Drilling

Polycrystalline Diamond Compact (PDC) Cutter is superhard material and consists of with polycrystalline diamond layer sintered with tungsten carbide substrate under ultra-high pressure and temperature. The PDC Cutters are extremely important since the drilling of shale formations requires excellent functional products to ensure efficiency during the drilling process. Practically, the rocks can be cut more efficiently by this product compared to simply crushing the rocks with a roller cone bit or grinding the rocks with the diamond impregnated bit.

Categories: ,
Request a quote

Description

Product  Advantage

Advanced technology, strict quality control, high speed and efficiency, low damage rate, high stability, and cost-effectiveness.

Product  Application

PDC cutters are widely and mainly applied for geological drill bits to shear rock with a continuous scraping motion, and also for machining the superhard tools, etc.

Product Characteristic

The PDC Cutters have high impact resistance, high abrasion resistance, good self-sharpening, and high thermal stability. The above factors significantly improve speed and machine feeding, and extend the tool’s service life. Polycrystalline diamond compacts are the most rigid diamond tool materials and the hardness of the polycrystalline layer approximates the natural diamond.

Product Size

Item Diameter (mm） Height(mm） Thickness(mm) Diamond Chamfer(mm) Substrate Chamfer(mm)
1308 13.44 8.00 2.2±0.10 0.25×45° 0.7×45°
1313 13.44 13.20 2.2±0.10 0.25×45° 0.7×45°
1608 15.88 8.00 2.2±0.10 0.25×45° 0.7×45°
1613 15.88 13.20 2.2±0.10 0.25×45° 0.7×45°
1616 15.88 16.00 2.2±0.10 0.25×45° 0.7×45°
1908 19.05 8.00 2.2±0.10 0.25×45° 0.7×45°
1913 19.05 13.20 2.2±0.10 0.25×45° 0.7×45°
1916 19.05 16.00 2.2±0.10 0.25×45° 0.7×45°
1919 19.05 19.00 2.2±0.10 0.25×45° 0.7×45°
